Magic Microphone for Admaster Paging System

SKU: MM1
Availability: Out of Stock - can backorder and will be dispatched once in stock.
Call for pricing
i h
Product Files

Professional Paging Made Simple

The Magic Microphone MM1 is a purpose-built microphone designed exclusively for the Admaster audio system. Engineered for retail and commercial environments, the MM1 makes professional-quality announcements as easy as making a phone call—no technical expertise required.


Why "Magic"?

The MM1 eliminates the most common problems with traditional paging microphones:

Automatic Volume Leveling - Whether someone speaks enthusiastically or quietly, the output is automatically balanced to professional broadcast levels. No more ear-piercing announcements from loud speakers or inaudible whispers from shy staff members.

Intelligent Priority Management - Color-coded buttons make it intuitive to choose the right priority level. Staff instinctively know which button to press without consulting a manual.

Zero Learning Curve - If you can make a phone call, you can use a Magic Microphone. The simple interface means new staff are productive immediately.


Key Features

Automatic Volume Control

The MM1's built-in intelligence automatically adjusts volume levels, so users simply speak in a normal conversational voice. The system handles the rest, delivering consistent, professional audio quality regardless of the speaker's natural volume or enthusiasm level.

Color-Coded Priority System

GREEN Button - General Announcements For everyday announcements that queue politely behind currently playing messages. Perfect for:

  • Departmental promotions
  • Product availability notifications
  • Staff communications
  • Customer service announcements

RED Button - High Priority / Emergency Interrupts current messages for time-critical or emergency announcements. Reserved for:

  • Emergency situations
  • Urgent safety notifications
  • Critical operational messages
  • Lost child announcements

WHITE Button - Record Interval Promotions Press and hold to record promotional messages that play automatically at set intervals throughout the day:

  • "Fresh hot chickens ready in the deli"
  • "New season cherries just arrived in produce"
  • "Special pricing on bakery items for the next hour"

YELLOW Button - Record Set Time Messages / Delete Records announcements that play at specific scheduled times:

  • Store opening/closing warnings
  • Department readiness announcements
  • Timed promotional messages

Also serves as the delete function—hold immediately after recording (within 5 seconds) to delete a message.

Optimal Microphone Technique Built-In

The MM1 is designed for the way people naturally speak:

Talk Over, Not Into - The microphone is positioned so users speak across the top of the element, not directly into it. This reduces plosives (popping P's and B's) and creates more natural-sounding announcements.

Automatic Distance Compensation - When held at the recommended 50mm (2 inches) from the mouth, the MM1 captures clear, intelligible audio. The automatic leveling system compensates for minor variations in distance.

Ambient Noise Rejection - Advanced filtering ensures background store noise doesn't interfere with announcements, even in busy retail environments.

Technical Specifications

Audio Performance

  • Element Type: Professional-grade dynamic capsule
  • Frequency Response: Optimized for voice clarity (300Hz - 3.4kHz emphasis)
  • Pickup Pattern: Cardioid (front-focused, rejects rear noise)
  • Automatic Gain Control: Built-in intelligence prevents clipping and normalizes volume
  • Output Level: Balanced, optimized for Admaster system

Physical Specifications

  • Connection Type: Proprietary Admaster connector (parallel wiring compatible)
  • Cable Length: [Standard length - check with manufacturer]
  • Mounting: Wall-mount cradle included
  • Construction: Durable commercial-grade housing
  • Weight: Lightweight for comfortable extended use
  • Finish: Professional matte finish, easy to clean

System Integration

  • Compatibility: Admaster TM6000e and compatible systems only
  • Maximum Units: Up to 16 Magic Microphones per system
  • Wiring Topology: Parallel connection (loop-in/loop-out, star, or combination)
  • Status Indicators: LED lights confirm recording and transmission

Environmental

  • Operating Temperature: Commercial environment rated
  • Humidity: Suitable for typical retail conditions
  • Durability: Impact-resistant housing
  • Cleaning: Grille removable for periodic cleaning

Installation & Placement

Wall Plate Connection

The MM1 connects via a standard wall plate installed at a height that prevents the microphone from touching the floor if dropped from the mounting cradle. Typical installation height is 1.2-1.5 meters (4-5 feet) from the floor.

Mounting Cradle

The included mounting cradle installs to the side of and slightly above the wall plate connection. This ergonomic positioning makes the microphone comfortable to use while keeping the cable organized.

Important: Mounting cradles in food preparation areas must meet local health department standards for wall-to-surface joints.

Identification Label

Each MM1 installation includes a "Magic Microphone" legend sticker placed alongside the mounting cradle. This is critical—it identifies the connection point as suitable for Magic Microphones only, preventing damage from connecting incompatible equipment.

Installation Considerations

Do Not Install:

  • In locations subject to washdown or heavy moisture
  • Where passing trolleys, carts, or equipment may cause damage
  • In areas where entanglement with cords or equipment is likely
  • In direct sunlight or extreme temperature locations

Ideal Locations:

  • Department manager workstations
  • Behind service counters
  • In back-of-house areas accessible to staff
  • Near department-specific work areas
  • At customer service desks
