Network Multi-Info Speaker, with 2 x Color LCD

ZYCOO IPS-M1-D2W Network Multi-Info Speaker (Dual-Sided)

The ZYCOO IPS-M1-D2W is a SIP speaker with a colour LCD on both sides and a strobe, built to hang from a wall or ceiling bracket where people approach from either direction. It plays announcements, shows the same message on both screens and flashes a strobe, so an alert is heard and seen along a whole corridor. It has dual microphones for two-way talkback and registers with the ZYCOO IP Audio Center or any third-party IP-PBX.

It suits corridors, open spaces, classrooms, public areas and other sites in education, healthcare, transport, commercial and industrial settings, where a message needs to be noticed from a distance and from both sides.

Two screens, one message

The two LCDs show synchronised content at the same time, so a person walking either way sees the same notice. The IPS-M1-D2W is the double-sided version of the IPS-M1-D1W, and is the better choice when the speaker will project from a wall or hang from a ceiling in a thoroughfare.

• Two colour LCDs: 16-bit RGB back-lit displays at 1920 x 480 pixels and 600 nits, with configurable text, background colours and display layouts.
• Alert templates: ready-made templates for alerts, with programmable strobe profiles for emergencies, lockdowns and evacuations.
• Strobe: red, green or blue with adjustable brightness.
• Caller ID: shows caller information on the screens during SIP calls.
• Idle screen: shows the time and date when no message is active.
• Event scheduler and countdown timer: run scheduled messages and countdowns on the displays.
• 8GB internal storage: holds audio files on the device.

Wi-Fi and wearable smart button support

The IPS-M1-D2W has dual-band Wi-Fi (802.11 a/b/g/n/ac/ax, 2.4GHz and 5GHz) as well as Ethernet, with dual-connection routing between the two. That suits corridors and buildings where running a cable to every position is difficult. It also has Bluetooth 5.0 with BLE, which lets it work with wearable smart buttons such as the IPS-K-BT1. A button press can start an alert, place a SIP call, recall a scene preset or operate a relay for a door lock or access system, within Bluetooth range and with no extra infrastructure.

Emergency alerts and scenes

Audio, both screens and the strobe start together when an alert is triggered. Lockdown, fire and intrusion scenes come pre-configured, and the strobe colour and pattern can be set for each event. Alerts can be triggered by a SIP call, the API, a switch input or a BLE wearable button. Scene presets combine text, colour and strobe, so a single trigger sets everything.

Audio and volume

Adaptive volume uses a separate ambient microphone and works in two modes. Static compensation measures noise before playback and applies a fixed adjustment. Dynamic compensation keeps re-sampling during playback and adjusts in real time, which suits lobbies, platforms and factory floors where noise changes. Full-duplex SIP intercom uses G.722 wideband audio.

Installation

A universal bracket is included and supports both wall and ceiling mounting. A single PoE+ cable carries power and network data.

Power options and output

The IPS-M1-D2W runs on PoE+, PoE or an external 24V/2A DC supply. Output depends on the source:

PoE+ is the intended power source. Standard PoE gives only 2 x 1.5W, which is very quiet, so use PoE+ or DC for real paging duty. Use DC if you want full output or want to connect over Wi-Fi.

Paging, talkback and integration

• Two-way talkback: dual microphone design for communication from the unit.
• Zone paging and multicast: multicast scales across large sites, and P2P allows direct audio between endpoints without a server.
• Three SIP registrations: register to more than one account or system.
• Standard SIP: works with the ZYCOO IP Audio Center and third-party IP-PBX platforms.
• ONVIF compatible: connects to video surveillance platforms for event-linked alerts.
• Flexible API and MQTT: integrate with automation tools and third-party platforms.
• Dry contact output and switch input: trigger external equipment, or start an alert from a button or sensor.

Installation and build

The housing is aluminium with a textured white epoxy finish. It mounts to a wall or ceiling using the supplied bracket, and the weight with bracket is 3kg. Configuration and monitoring are done through a web interface, so messages, templates and strobe profiles can be changed remotely. The operating range is -20°C to 50°C. The warranty is 24 months.

Specifications

Frequently asked questions

What is the difference between the IPS-M1-D1W and the IPS-M1-D2W?
The D1W has one screen and mounts flat to a wall. The D2W has a screen on each side, with two speakers, and mounts to a wall or ceiling bracket so it can be seen from both directions.

Does it need PoE+?
PoE+ is recommended. Standard PoE gives only 2 x 1.5W output. For full output, use PoE+ or a 24V/2A DC supply.

Can it connect over Wi-Fi?
Yes. It supports dual-band Wi-Fi and Ethernet, with dual-connection routing between the two.

Is a mounting bracket included?
Yes. A universal bracket for wall or ceiling mounting is included.

What can a wearable button do?
It can start an alert, place a SIP call, recall a scene preset or operate a relay for door locks and access systems.

Does it work with wearable panic buttons?
It supports BLE-based wearable smart buttons to trigger emergency alerts, such as the IPS-K-BT1.

Can it be ceiling mounted?
Yes. It mounts to a wall or ceiling using the bracket.

Does it need a separate amplifier?
No. It has a built-in Class-D amplifier and works as a standalone network speaker.

Does it work with third-party phone systems?
Yes. It uses standard SIP and works with the ZYCOO IP Audio Center and other third-party IP-PBX systems.

What warranty does it have?
24 months.
