System
Wireless Technology	Digital UHF
Number of RF Channel Frequencies	3200
Included Transmitters	2 x Handheld
Diversity	Intelligent Switching Diversity
RF Frequency Band	S4-10: 630 - 693.8 MHz
RF Channel Scanning	Auto-Scan
Max Operating Range	328.1' / 100 m (Line of Sight)
Max Transmitters per Band	269
Built-In Recorder	No
Control App Support	Yes, Available for Android/iOS
Bluetooth	5.1 LE
Bluetooth Operating Distance	120' / 36.6 m (Transmitter Sync, App Control)
Sample Rate/Resolution	24-Bit
Latency	1.9 ms
Dynamic Range	134 dB
Encryption	AES 256
Receiver
Receiver Type	Tabletop / Rackmount
Mounting Options	Rackmount (with Included Hardware)
Rackmount Size	1 RU (1/2 Rack)
Antenna	2 x 1/4 Wave Rod, BNC (Rear-Mount)
Number of Audio Channels	2
Audio I/O	2 x XLR 3-Pin Male Balanced Output 2 x 1/4" TS Female Unbalanced Output
Audio Output Level	+18 dBu (Max) +12 dBu (Max)
Frequency Response	20 Hz to 20 kHz ±3 dB
Network I/O	1 x RJ45
Word Clock I/O	None
USB/Lightning Connectivity	None
RF Output Power	10 mW (EIRP)
Power Requirements	AC/DC Power Adapter, PoE
AC/DC Power Adapter	11 to 13 VDC (Included)
DC Input Power	12 VDC
AC Input Power	100 to 240 VAC, 50 / 60 Hz
Display & Indicators	1 x OLED (AF Level, Channel, Frequency, Output Level, RF Level, Transmitter Battery Status)
Housing	Metal
Operating Temperature	14 to 131°F / -10 to 55°C
Operating Humidity	5 to 95%
Dimensions	8.3 x 1.7 x 7.4" / 212 x 44 x 189 mm
Weight	2.2 lb / 1 kg (without Antenna)
