DMX cable, 5 metres 5 pin M to 5pin F

5-pin DMX Cable (5m)  XLR5M5F5

The Event Lighting XLR5M5F1.5 is a high-quality 5-pin DMX cable designed for reliable DMX signal transmission in lighting control setups. Measuring 5 metres and identified with a blue ring, this cable is clearly colour-coded and features clear heat shrink labelling to easily distinguish it from audio cables.

Built for professional use, it features a durable black metal 5-pin XLR connector with a metal boot and rubber gland for strain relief, ensuring a secure and long-lasting connection.

Specifications:

• Length: 5 metres (blue ring)

• Conductor: 0.34 mm² (19x0.15mm)

• Insulation: PE

• Core Arrangement: 4 twisted cores

• Shielding: AL/PET + braided with 20x0.12 drain

• Outer Jacket: PVC Ø7.5mm

• Connectors: 5-pin XLR (black metal with rubber gland and boot)

• Shipping Weight: .65 kg

• Dimensions: 350 x 100 x 20 mm

• Warranty: 7 days

Features:

• Length: 5 metres
• Conductor: 0.34 mm²
• Insulation: PE
• Core arrangement: 4 cores, twisted
• Shielding: AL/PET + Braided
• Outer Jacket: PVC ?7.5 mm
• Cable Material: 19x0.15mm core, 16x16x0.12 cotton, aluminium foil shield and 20x0.12 drain
• 5 Pin XLR connector: Black metal connector with metal boot and rubber gland
• The colour coding and clear heat shrink on the end of each cable indicates your DMX cables
• 5m length, green ring.
• Shipping Weight: 0.65 kg
• Dimensions: 310 x 120 x 50 mm

Product Specification Sheet Download

Warranty: 7 days
