60 watt Public Address Amplifier Mixer, 4 Mic, 4 Aux

FP Series PA Mixer Amplifier T-60FP

The FP Series PA Amplifiers (T-60FP & T-240FP) are versatile 2U rack-mountable mixer amplifiers, designed for public address, paging, and background music applications in commercial, educational, and industrial settings. With 70V, 100V, and 4-16Ω speaker outputs, these amplifiers provide powerful, clear audio for public address, music and paging sound systems.

With dual power operation (AC 230V & DC 24V), this amplifier is backup power-ready, making it ideal for emergency paging systems.

Key Features:

60W (T-60FP) & 240W (T-240FP) Power Output – Suitable for small to medium PA systems
Multiple Audio Inputs:

• 4 Balanced XLR Microphone Inputs with phantom power & gain control

• 4 Dual RCA Line Inputs (Rear Panel)

• 4 Audio Source Selectors (Front Panel)
  Built-in Chime with Remote Trigger – Pre-announcement chime with volume control & 2/4 tone selector
  Priority Mic Function – Mic 1-4 have selectable priority over other inputs
  Flexible Output Options:

• XLR Balanced Line Output – For connecting extra power amplifiers

• REC Output – For recording or driving another zone

• PRE Output & AMP Input – Allows integration with signal processors (mixers, equalizers, etc.)
  Master, Mic1-4 & Aux Volume Controls – Plus treble & bass adjustments for fine-tuned sound
  Full Protection Circuitry:

• Short Circuit, Thermal Overload & Overload Protection
  Dual Power Options:  AC 220-240V & DC 24V Operation

• Compact & Rack-Mountable Design:

• Dimensions: 484 x 335 x 88mm

• Weight: 7.5kg

Ideal For:

• Retail Stores, Shopping Centres & Public Spaces

• Schools, Universities & Conference Rooms

• Churches, Places of Worship & Community Halls

• Factories, Warehouses & Large Offices

• Paging, Background Music & Multi-Zone PA Systems

The FP Series PA Amplifier is a reliable, feature-packed solution for any public address or background music application.
